Products Description
Buyer application note: The 24W LED Spotlight with Lampshade | IP65 Outdoor Garden Accent Light is a 24W outdoor spotlight for compact facade, signage, garden and architectural accent lighting projects. Before quotation, confirm mounting position, beam angle, CCT or RGB/RGBW control, cable entry, accessory requirements, and available compliance documents for the target market.
Project selection path: When specifying 24W LED Spotlight with Lampshade, compare 3W Mini LED Garden Spike Spotlight | IP66 RGBW DMX Accent Light, S Series LED Garden Spike Lights | 1W-15W Low-Power Landscape Accent Lighting, Z Series COB LED Landscape Spot Lights | 10W-30W Outdoor Accent Lighting, 3W Square LED Spotlight | IP67 Garden Wall Accent Light to confirm beam angle, mounting, glare control, waterproof protection and quotation details before final selection.
This 24W IP65 outdoor LED spotlight is the practical option for illuminating facade details, garden landscapes, boundary walls, and exterior accent areas. It is designed to work in all kinds of outdoor conditions and offers superior illumination while being highly energy-efficient. With its IP67 rating, it is dustproof and waterproof, ensuring long-term performance and reliability. This LED spotlight is a great choice for outdoor lighting applications, as it will provide a bright, consistent, and cost-effective light source that can be used for years to come.
Features
DMX optional RGB RGBW LED Flood Light
DC24V Input for more safety outdoor application
CREE/OSRAM LEDs with 90+ Lumens per Watt
Superior Optical Design with 8° /15°/ 30°/45°/60°
International Certification: compliance documents confirmed per project
Architectural Floodlighting, Facade Lighting
Landscape Lighting, Garden Spotlighting
| Model No. | D130-24W |
|---|---|
| Input Voltage | AC100-240V or DC24V |
| PF | >0.85 |
| Power Consumption | 24W |
| LED | CREE or LUMILEDS LED |
| LED Lifetime | >50000 hours |
| CCT | 1800K-6000K / Single Color / RGB |
| CRI | Ra>80 |
| Luminous Flux | 1920lm |
| Beam Angle | 8° /15°/ 30°/45°/60° |
| Control | ON/OFF or DMX |
| Main Material | Die-cast Aluminum + Tempered Glass |
| Shell Color | Silver gray |
| Dimensions | Ø130*136*169mm |
| Weight | 1.5KG |
| IP Rating | IP65 |
| Mounting | Bracket for Surface Mount |
| Working Temperature | -20℃~45℃ |
| Storage Temperature | -30℃~50℃ |
| Humidity | 15%-90%RH |
| Certification | CE RoHS |
Project Selection Notes
This outdoor spotlight with a visor or lampshade is useful when the project needs more controlled light direction, softer visual comfort, or reduced spill light compared with a fully exposed fixture. It is suitable for garden features, facade details, pathways, commercial landscapes, and hospitality exterior lighting.
Before Requesting a Quote
- Confirm target object, mounting distance, and approximate installation height.
- Confirm white, RGB, or RGBW color requirement and whether DMX512 control is needed.
- Confirm beam angle preference, quantity, cable route, and outdoor exposure conditions.
- Send drawings or site photos so fixture power, aiming, mounting, and accessories can be checked together.
Related Products and Guides
For stronger glare-control accessories, compare D22 anti-glare caps, radar and louver anti-glare rings, and deep anti-glare pressure plates. For higher output, review high-power LED flood lights. For a broader selection workflow, read the beam angle, IP rating and DMX512 RGBW outdoor lighting guide, or visit the catalog and datasheet downloads.
FAQ
How should this spotlight be selected?
Start from the target size, mounting distance, installation surface, color mode, and required beam angle rather than wattage alone.
Can it be used in RGB or RGBW projects?
Several Radiant Honor outdoor spotlight ranges support RGB/RGBW and DMX project options, but the exact configuration should be confirmed by model and project requirement.
What information helps quotation accuracy?
Project photos, drawings, quantity, color mode, control method, beam angle preference, and mounting condition are the most useful details.
Procurement Checklist for This Model
This 24W outdoor LED spotlight with lampshade is mainly used for compact outdoor accents, garden features, wall details and glare-managed lighting. Before confirming the order, review the practical project details below so the selected fixture, beam angle, mounting method and control option match the real installation environment.
- Application zone, target size and approximate projection or viewing distance.
- Mounting method, mounting height, cable direction and maintenance access.
- Beam angle, color temperature, RGB/RGBW, dimming or DMX512 requirement.
- Outdoor exposure, glare direction, accessory requirement and power supply position.
- Drawings, IES files, datasheets or installation references needed from the download center.
